Polymers are substances containing a large number of structural units joined by the same type of linkage. These substances often form into a chain-like structure. Polymers in the natural world have been around since the beginning of time. Starch, cellulose, and rubber all possess polymeric properties. Man-made polymers have been studied since 1832. Today, the polymer industry has grown to be larger than the aluminum, copper and steel industries combined.

Polymers already have a range of applications that far exceeds that of any other class of material available to man. Current applications extend from adhesives, coatings, foams, and packaging materials to textile and industrial fibers, composites, electronic devices, biomedical devices, optical devices, and precursors for many newly developed high-tech ceramics.

A polymer is a large molecule (macromolecule) composed of repeating structural units typically connected by covalent chemical bonds. While polymer in popular usage suggests plastic, the term actually refers to a large class of natural and synthetic materials with a variety of properties and purposes.

Well-known examples of polymers include plastics and proteins. A simple example is polypropylene, whose repeating unit structure is shown at the right. However, polymers are not just limited to having predominantly carbon backbones, elements such a silicon form familiar materials such as silicones, examples being silly putty and waterproof plumbing sealant. The backbone of DNA is in fact based on a phosphodiester bond.

Natural polymer materials such as shellac and amber have been in use for centuries. Biopolymers such as proteins and nucleic acids play crucial roles in biological processes. A variety of other natural polymers exist, such as cellulose, which is the main constituent of wood and paper

The list of synthetic polymers includes Bakelite, neoprene, nylon, PVC, polystyrene, polyacrylonitrile, PVB, silicone, and many more.

Polymers are studied in the fields of polymer chemistry, polymer physics, and polymer science

History

Polymer Synthesis

The study of polymer science begins with understanding the methods in which these materials are synthesized. Polymer synthesis is a complex procedure and can take place in a variety of ways. Addition polymerization describes the method where monomers are added one by one to an active site on the growing chain.

Addition Polymerization

The most common type of addition polymerization is free radical polymerization. A free radical is simply a molecule with an unpaired electron. The tendency for this free radical to gain an additional electron in order to form a pair makes it highly reactive so that it breaks the bond on another molecule by stealing an electron, learing that molecule with an unpaired election (which is another free radical). Free radicals are often created by the division of a molecule (known as an initiator) into two fragments along a single bond. The following diagram shows the formation of a radical from its initiator, in this case benzoyl peroxide.

Thestabilityof a radical refers to the molecule's tendency to react with other compounds. An unstable radical will readily combine with many different molecules. However a stable radical will not easily interact with other chemical substances. The stability of free radicals can vary widely depending on the properties of the molecule. The active center is the location of the unpaired electron on the radical because this is where the reaction takes place. In free radical polymerization, the radical attacks one monomer, and the electron migrates to another part of the molecule. This newly formed radical attacks another monomer and the process is repeated. Thus the active center moves down the chain as the polymerization occurs.

There are three significant reactions that take place in addition polymerization: initiation (birth), propagation (growth), and termination (death). These separate steps are explained below.

Initiation Reaction

The first step in producing polymers by free radical polymerization is initiation. This step begins when an initiator decomposes into free radicals in the presence of monomers. The instability of carbon-carbon double bonds in the monomer makes them susceptible to reaction with the unpaired electrons in the radical. In this reaction, the active center of the radical "grabs" one of the electrons from the double bond of the monomer, leaving an unpaired electron to appear as a new active center at the end of the chain. Addition can occur at either end of the monomer. This process is illustrated in the following animation in which a chlorine atom possessing an unpaired electron (often indicated as cl-) initiates the reaction. As it collides with an ethylene molecule, it attracts one of the ethylene's pair of pi bonded electrons in forming a bond with one of the carbons. The other pi electron becomes the active center able to repeat this process with another ethylene molecule. The sigma bond between the carbons of the ethylene is not disturbed. (Note that a molecular orbital model is employed here in describing this process. See any introductory college chemistry text for further discussion)

In a typical synthesis, between 60% and 100% of the free radicals undergo an initiation reaction with a monomer. The remaining radicals may join with each other or with an impurity instead of with a monomer. "Self destruction" of free radicals is a major hindrance to the initiation reaction. By controlling the monomer to radical ratio, this problem can be reduced.

Propagation Reaction

After a synthesis reaction has been initiated, the propagation reaction takes over. In the propagation stage, the process of electron transfer and consequent motion of the active center down the chain proceeds. In this diagram, (chain) refers to a chain of connected monomers, and X refers to a substituent group (a molecular fragment) specific to the monomer. For example, if X were a methyl group, the monomer would be propylene and the polymer, polypropylene.

In free radical polymerization, the entire propagation reaction usually takes place within a fraction of a second. Thousands of monomers are added to the chain within this time. The entire process stops when the termination reaction occurs.

Termination Reaction

In theory, the propagation reaction could continue until the supply of monomers is exhausted. However, this outcome is very unlikely. Most often the growth of a polymer chain is halted by the termination reaction. Termination typically occurs in two ways:combination and disproportionation.

Combination occurs when the polymer's growth is stopped by free electrons from two growing chains that join and form a single chain. The following diagram depicts combination, with the symbol (R) representing the rest of the chain.

Disproportionation halts the propagation reaction when a free radical strips a hydrogen atom from an active chain. A carbon-carbon double bond takes the place of the missing hydrogen. Termination by disproportionation is shown in the diagram.

Disproportionation can also occur when the radical reacts with an impurity. This is why it is so important that polymerization be carried out under very clean conditions.

Properties of polymers

Physical properties of polymers include the degree of polymerization, molar mass distribution, crystallinity, as well as the thermal phase transitions: Tg, glass transition temperature Tm, melting point (for thermoplastics). Polymer - Branching. During the propagation of polymer chains, branching can occur. In free-radical polymerization, this occurs when a chain curls back and bonds to an earlier part of the chain. When this curl breaks, it ...

Physical properties of polymers include the degree of polymerization, molar mass distribution, crystallinity, as well as the thermal phase transitions:

• Tg, glass transition temperature
• Tm, melting point (for thermoplastics).

Polymer - Branching

During the propagation of polymer chains, branching can occur. In free-radical polymerization, this occurs when a chain curls back and bonds to an earlier part of the chain. When this curl breaks, it leaves small chains sprouting from the main carbon backbone. Branched carbon chains cannot line up as close to each other as unbranched chains can. This causes less contact between atoms of different chains, and fewer opportunities for induced or permanent dipoles to occur. A low density results from the chains being further apart. Lower melting points and tensile strengths are evident, because the intermolecular bonds are weaker and require less energy to break.

Besides branching, polymers can have other topologies: linear, network (cross-linked 3D structure), IPN (integrated polymer network), comb, or star as well as dendrimer and hyperbranched structures.

Polymer - Stereoregularity

Stereoregularity or tacticity describes the isomeric arrangement of functional groups on the backbone of carbon chains. Isotactic chains are defined as having substituent groups aligned in one direction. This enables them to line up close to each other, creating crystalline areas and resulting in highly rigid polymers.

In contrast, atactic chains have randomly aligned substituent groups. The chains do not fit together well and the intermolecular forces are low. This leads to a low density and tensile strength, but a high degree of flexibility.

Syndiotactic substituent groups alternate regularly in opposite directions. Because of this regularity, syndiotactic chains can position themselves close to each other, though not as close as isotactic polymers. Syndiotactic polymers have better impact strength than isotactic polymers because of the higher flexibility resulting from their weaker intermolecular forces.

Relationship between chain length and polymer properties

Polymer bulk properties are strongly dependent upon their structure and mesoscopic behavior. A number of qualitative relationships between structure and properties are known.

Increasing chain length tends to decrease chain mobility, increase strength and toughness, and increase the glass transition temperature (Tg). This is a result of the increase in chain interactions such as Van der Waals attractions and entanglements that come with increased chain length. These interactions tend to fix the individual chains more strongly in position and resist deformations and matrix breakup, both at higher stresses and higher temperatures. Chain length is related to melt viscosity roughly as 1:103.2, so that a tenfold increase in polymer chain length results in a viscosity increase of over 1000 times.

Crystallinity

When applied to polymers, the term crystalline has a somewhat ambiguous usage. In some cases, the term crystalline finds identical usage to that used in conventional crystallography. For example, the structure of a crystalline protein or polynucleotide, such as a sample prepared for x-ray crystallography, may be defined in terms of a conventional unit cell composed of one or more polymer molecules with cell dimensions of hundreds of angstroms or more.

A synthetic polymer may be lightly described as crystalline if it contains regions of three-dimensional ordering on atomic (rather than macromolecular) length scales, usually arising from intramolecular folding and/or stacking of adjacent chains. Synthetic polymers may consist of both crystalline and amorphous regions; the degree of crystallinity may be expressed in terms of a weight fraction or volume fraction of crystalline material. Few synthetic polymers are entirely crystalline.

The crystallinity of polymers is characterized by their degree of crystallinity, ranging from zero for a completely noncrystalline polymer to one for a theoretical completely crystalline polymer. Increasing degree of crystallinity tends to make a polymer more rigid. It can also lead to greater brittleness. Polymers with a degree of crystallinity approaching zero or one will tend to be transparent, while polymers with intermediate degrees of crystallinity will tend to be opaque due to light scattering by crystalline or glassy regions.

Tensile strength

The tensile strength of a material quantifies how much stress the material will endure before failing. This is very important in applications that rely upon a polymer's physical strength or durability. For example, a rubber band with a higher tensile strength will hold a greater weight before snapping. In general tensile strength increases with polymer chain length.

Young's modulus of elasticity

Young's Modulus quantifies the elasticity of the polymer. It is defined, for small strains, as the ratio of rate of change of stress to strain. Like tensile strength, this is highly relevant in polymer applications involving the physical properties of polymers, such as rubber bands. The modulus is strongly dependent on temperature.

Transport properties

Transport properties such as diffusivity relate to how rapidly molecules move through the polymer matrix. These are very important in many applications of polymers for films and membranes.

Melting point

The term melting point, when applied to polymers, suggests not a solid-liquid phase transition but a transition from a crystalline or semi-crystalline phase to a solid amorphous phase. Though abbreviated as simply Tm, the property in question is more properly called the crystalline melting temperature. Among synthetic polymers, crystalline melting is only discussed with regards to thermoplastics, as thermosetting polymers will decompose at high temperatures rather than melt.

Boiling point

The boiling point of a polymer substance is never defined because polymers will decompose before reaching theoretical boiling temperatures.

Glass transition temperature

A parameter of particular interest in synthetic polymer manufacturing is the glass transition temperature (Tg), which describes the temperature at which amorphous polymers undergo a second-order phase transition from a rubbery, viscous amorphous solid to a brittle, glassy amorphous solid. The glass transition temperature may be engineered by altering the degree of branching or crosslinking in the polymer or by the addition of plasticizer

Mixing behavior

In general, polymeric mixtures are far less miscible than mixtures of small molecule materials. This effect is a result of the fact that the driving force for mixing is usually entropics, not energetics. In other words, miscible materials usually form a solution not because their interaction with each other is more favorable than their self-interaction, but because of an increase in entropy and hence free energy associated with increasing the amount of volume available to each component. This increase in entropy scales with the number of particles (or moles) being mixed. Since polymeric molecules are much larger and hence generally have much higher specific volumes than small molecules, the number of molecules involved in a polymeric mixture are far less than the number in a small molecule mixture of equal volume. The energetics of mixing, on the other hand, are comparable on a per volume basis for polymeric and small molecule mixtures. This tends to increase the free energy of mixing for polymer solutions and thus make solvation less favorable. Thus, concentrated solutions of polymers are far rarer than those of small molecules.

In dilute solution, the properties of the polymer are characterized by the interaction between the solvent and the polymer. In a good solvent, the polymer appears swollen and occupies a large volume. In this scenario, intermolecular forces between the solvent and monomer subunits dominate over intramolecular interactions. In a bad solvent or poor solvent, intramolecular forces dominate and the chain contracts. In the theta solvent, or the state of the polymer solution where the value of the second virial coefficient becomes 0, the intermolecular polymer-solvent repulsion balances exactly the intramolecular monomer-monomer attraction. Under the theta condition (also called the Flory condition), the polymer behaves like an ideal random coil.

Chain conformation

The space occupied by a polymer molecule is generally expressed in terms of radius of gyration, which is an average distance from the center of mass of the chain to the chain itself. Alternatively, it may be expressed in terms of pervaded volume, which is the volume of solution spanned by the polymer chain and scales with the cube of the radius of gyration.

Chemical crosslinking

Crosslinking tends to increase Tg and increase strength and toughness. Crosslinking consists of the formation of chemical bonds between chains. Among other applications, this process is used to strengthen rubbers in a process known as vulcanization, which is based on crosslinking by sulphur. Car tires, for example, are highly crosslinked in order to reduce the leaking of air out of the tire and to toughen their durability. Eraser rubber, on the other hand, is not crosslinked to allow flaking of the rubber and prevent damage to the paper.

Inclusion of plasticizers

Inclusion of plasticizers tends to lower Tg and increase polymer flexibility. Plasticizers are generally small molecules that are chemically similar to the polymer and create gaps between polymer chains for greater mobility and reduced interchain interactions. A good example of the action of plasticizers is related to polyvinylchlorides or PVCs. A uPVC, or unplasticized polyvinylchloride, is used for things such as pipes. A pipe has no plasticizers in it, because it needs to remain strong and heat-resistant. Plasticized PVC is used for clothing for a flexible quality. Plasticizers are also put in some types of cling film to make the polymer more flexible.

Applications of Polymers:

Agriculture and Agribusiness

• Polymeric materials are used in and on soil to improve aeration, provide mulch, and promote plant growth and health.

Medicine

• Many biomaterials, especially heart valve replacements and blood vessels, are made of polymers like Dacron, Teflon and polyurethane.

Consumer Science

• Plastic containers of all shapes and sizes are light weight and economically less expensive than the more traditional containers. Clothing, floor coverings, garbage disposal bags, and packaging are other polymer applications.

Industry

• Automobile parts, windshields for fighter planes, pipes, tanks, packing materials, insulation, wood substitutes, adhesives, matrix for composites, and elastomers are all polymer applications used in the industrial market.

Sports

• Playground equipment, various balls, golf clubs, swimming pools, and protective helmets are often produced from polymers.

References:
Matse1.mse.uiuc.edu
www.chm.bris.ac.uk
plc.cwru.edu
www.experiencefestival.com
en.wikipedia.org
www.polymer.com
pslc.ws
www.che.iitm.ac.in
www.chemcomp.com

Editorial Team, Mindfiesta
